SPECIFICATIONS
Notes:
Temperature categorized in 4 models.
T1=100 °CT2=125 °CT3=150 °C T4=180 °CT5 above 180 °C
| Fabric type | Fabric structure | Fabric type | Fabric thickness | Cover rubber thickness | Width | Length | ||
| warp | weft | Upper | Lower | |||||
| EP | EP | EP | EP-100 | 0.75 | 1.5-8 | 0-4.5 | 400-2500 | <=300 |
| EP-150 | 0.80 | |||||||
| EP-200 | 0.90 | 500-2500 | ||||||
| EP-250 | 1.15 | |||||||
| EP-300 | 1.25 | |||||||
| EP-400 | 1.45 | 800-2500 | ||||||
| EP-500 | 1.55 | |||||||
We could offer belt with cover grade in accordance to International standard such as DIN 22102, RMA, AS 1332, SABS 1173/2000, IS 1891, BS 490, JIS K 6322, etc.
| Standards | Cover Rubber | Adhesion | ||||
| Tensile Strength | Elongation at break | Abrasion | Cover to Ply | Cover to Ply | Ply to Ply | |
| DIN 22102 | Mpa | % | mm3 | N/mm (≤1.5mm) | N/mm (>1.5mm) | N/mm |
| DIN 22102-Z | 15 | 350 | 250 | 3.5 | 4.5 | 5 |
| DIN 22102-W | 18 | 400 | 90 | 3.5 | 4.5 | 5 |
| DIN 22102-Y | 20 | 400 | 150 | 3.5 | 4.5 | 5 |
| DIN 22102-X | 25 | 450 | 120 | 3.5 | 4.5 | 5 |
| Standards | Cover Rubber | Adhesion | ||||
| Tensile StrengTD | Elongation at break | Abrasion | Cover to Ply | Cover to Ply | Ply to Ply | |
| AS 1332 | Mpa | % | mm3 | N/mm (≤1.9mm) | N/mm (>1.9mm) | N/mm |
| AS 1332-N17 | 17 | 400 | 200 | 4 | 4.8 | 6 |
| AS 1332-M24 | 24 | 450 | 125 | 4 | 4.8 | 6 |
