Conveyor Belt Usage and Maintenance Instructions

Conveyor belt definition: conveyor belt, also known as transport belt, is used for carrying and transporting materials in the belt conveyor belt rubber and fiber, metal composite products, or plastic and fabric composite products. A conveyor belt is widely used in agriculture, industrial and mining enterprises and transportation to transport a variety of solid block and powder-like materials or articles. The conveyor belt can be continuous, high efficiency, large Angle of transport, easy to use, easy maintenance, low freight, and can shorten the transport distance, reduce the project cost, save manpower and material resources.

With the improvement of mechanization and automation, the conveyor belt has been widely used in various industries in recent years. The conveyor belt has the function of the economy, automation, and improving effective power. The main component of its conveying system is the conveyor belt, but the rated failure of the conveyor belt often leads to a shutdown. China belt roller supplier explains how to maintain and maintain the belt Conveyor system in order to extend the service life of the belt conveyor system.

Usage of conveyor belt

1. During transportation and storage, the conveyor belt should be kept clean to avoid direct sunlight or rain and snow, to prevent contact with acid, alkali, oil, organic solvents, and other substances, and at least one meter away from the source of heat;

2. During storage, the temperature in the warehouse should be kept between -18℃ and 40℃, and the relative temperature should be between 50% and 80%;

3. During storage, the product shall be placed in rolls and shall not be folded. During storage, the product shall be turned over quarterly.

4. Conveyor belts of different types and specifications should not be connected together, and the joints should be glued together.

5. Types, structures, specifications, and layers of conveyor belt shall be selected reasonably according to the conditions of use;

6. For materials with large conveying belt lumpiness and large abrasion, and for the use of fixed type unloading device, low speed should be adopted as far as possible;

7. The relation between the diameter of the conveyor's driving drum and the conveyor belt's cloth layer, the matching of the driving drum, the changing drum and the requirements for the groove Angle of the supporting roller should be selected reasonably according to the design regulations of the conveyor;

8. The feeding direction should follow the running direction of the conveyor belt. In order to reduce the impact of falling materials on the conveyor belt, a chute should be used to reduce the falling distance of materials. The feeding section of the conveyor belt should shorten the distance between rollers and adopt buffer rollers. In order to prevent material leakage, the belt side should adopt a soft and moderate baffle plate, so as to prevent the baffle plate from being too hard and scraping the belt surface of the conveyor belt.

Coal Mine Conveyor Belt

Matters needing attention when using coal mine Conveyor belt

1, Avoid the trough idler is covered by the material, resulting in rotation failure, prevent material leakage stuck between the roller and the belt, pay attention to the lubrication of the moving part, but not oil conveyor belt;

2. Avoid starting with load;

3. If the tape runs out of alignment, timely measures shall be taken to correct it;

4. Local damage of conveyor belt should be repaired or replaced in time to avoid expansion.
